Buckets - Loader

2.1 m3 (2.7 yd3), Fusion™ Coupler, Bolt-On Cutting Edge

Excellent versatility for re-handling, clamping, dozing, grading, leveling and dumping.

Specifications
Features

Overview

Multi-Purpose Buckets for Cat® Small Wheel Loaders offer excellent versatility by enabling one work tool to do the job of many. This bucket is ideal for material handling, clamping, grading, leveling and grasping irregularly shaped objects.

UNITS:

Metric

Imperial

Width	2550 mm	100.4 in
Height	1274 mm	50.2 in
Weight	1417 kg	3123.9 lb
Length	1213 mm	47.8 in
Interface Type	Fusion™ Coupler	Fusion™ Coupler
Capacity	2.1 m³	2.7 yd³
Base Edge Thickness	25 mm	1 in
Cutting Edge Thickness	25 mm	1 in
Jaw Opening	1134 mm	44.6 in
Clam Angle	71 degrees	71 degrees
Required Hydraulics	3rd Function	3rd Function

Features

Application

Ideal for digging, dozing, clamping, back dragging, grading and leveling in construction, landscaping, industrial and demolition applications.

Bucket Design

Excellent clamping force lets you grasp large, irregularly shaped objects such as trees, loose stumps, brush, recycling debris and pipe, increasing the versatility of the machine.

Serrated Clam Sidewall

Aids in grasping material and ensuring it stays within the bucket.

Ground Engaging Tools

Base bucket also available with bolt-on cutting edge and bolt-on teeth.
