Engine

Gross Power - SAE J1995

1193 kW

1600 hp

Net Power - SAE J1349

1125 kW

1509 hp

Engine Model

Cat 3512E

Cat® 3516E

Cat® C175-16

Emissions Rating

Fuel Optimized

Bore

170 mm

6.7 in

170 mm

6.7 in

175 mm

7 in

Stroke

215 mm

8.5 in

215 mm

8.5 in

220 mm

9 in

Displacement

58.56 l

3573 in³

7.8 l

4766 in³

85 l

5187 in³

Note (1)

Net Power advertised is the power available at the flywheel when the engine is equipped with air intake system, exhaust system, and alternator.

Net Power advertised is the power available at the flywheel when the engine is equipped with air intake system exhaust system and alternator.

Note (2)

U.S. EPA Tier 4 Final / EU Stage V available for applicable markets.

Optional 1417 kW / 1,900 HP engine rating.

Note (3)

Additional fuel optimized selectable power ratings: 1,450 hp

U.S. EPA Tier 4 Final / EU Stage V optional engine available for applicable markets.

U.S. EPA Tier 4 Final / EU Stage V available for applicable markets.

Gross Power - SAE J1995:2014

1566 kW

2100 hp

1976 kW

2650 hp

Net Power - SAE J1349:2011

1473 kW

1975 hp

1886 kW

2529 hp

Rated Speed

1650 r/min

1750 r/min

Weights - Approximate

Nominal Rated Payload (33.00R51 Tires)

139 t

153 ton (US)

Rated Gross Machine Weight (33.00R51 tires)

249476 kg

550000 lb

Nominal Rated Payload (36.00R51 Tires)

142 t

157 ton (US)

Rated Gross Machine Weight (36.00R51 tires)

255826 kg

564000 lb

Chassis Weight (33.00R51 Tires)

84731 kg

186799 lb

Chassis Weight (36.00R51 Tires)

87631 kg

193192 lb

Body Weight

26208 kg

57779 lb

27400 kg

60406 lb

30151 kg

66471 lb

Note (1)

Consult your tire manufacturer for maximum tire load

Note (2)

Chassis weight with full fuel and fluids, standard & mandatory attachments, hoist, body mounting group, rims, and tires.

Chassis weight with full fuel and fluids, standard and mandatory attachments, hoist, body mounting group, rims, and tires.

Chassis weight with full fuel and fluids standard and mandatory attachments hoist body mounting group rims and tires.

Note (3)

Body weight varies depending on body selection and configuration.

Rated Gross Machine Weight

324318 kg

715000 lb

404000 kg

890668 lb

Nominal Rated Payload

193 t

213 ton (US)

240 t

265 ton (US)

Chassis Weight

133854 kg

295098 lb

Weight Distributions - Approximate

Front Axle - Empty

48%

50%

51%

Rear Axle - Empty

52%

50%

49%

Front Axle - Loaded

33%

Rear Axle - Loaded

67%

Note

Weight distributions optimized with Cat body.

Final Drives

Type

Double reduction, planetary with full floating axles.

Double reduction, planetary with full floating axles

Differential Ratio

2:10:01

2.35:1

1.8:1

Planetary Ratio

10.83:1

Total Reduction Ratio

22.75:1

25.46:1

Note

Double reduction planetary with full floating axles.

Transmission

Forward - 1

12 km/h

7.4 mile/h

12.6 km/h

7.8 mile/h

12 km/h

8 mile/h

Forward - 2

16.2 km/h

10 mile/h

17.1 km/h

10.6 mile/h

16 km/h

10 mile/h

Forward - 3

22.1 km/h

13.7 mile/h

23.1 km/h

14.4 mile/h

22 km/h

14 mile/h

Forward - 4

29.8 km/h

18.5 mile/h

31.2 km/h

19.4 mile/h

30 km/h

19 mile/h

Forward - 5

40.2 km/h

25 mile/h

42.3 km/h

26.3 mile/h

41 km/h

26 mile/h

Forward - 6

57.2 km/h

35.6 mile/h

57.2 km/h

35.5 mile/h

60 km/h

37 mile/h

Reverse

11.6 km/h

7.2 mile/h

11.8 km/h

7.3 mile/h

11 km/h

7 mile/h

Top Speed - Loaded

57.2 km/h

35.6 mile/h

57.2 km/h

35.5 mile/h

60 km/h

37 mile/h

Note

Maximum travel speeds with standard 33.00-R51 tires.

Tires

Standard Tire

33.00R51

Optional Tire

36.00R51

42/90 R57

Rims

610 mm (24") Rims (standard). 660 mm (26") Rims (optional).

29” x 57” Rims

Note (1)

Quick Change Rims optional.

Quick Change Rims optional

Note (2)

Caterpillar recommends the customer evaluate all job conditions and consult tire manufacturer for proper tire selection and TKPH (TMPH) capabilities.

Standard Tires

37 R57

737 mm (29 in)

Optional Tires

40 R57

813 mm (32 in)

Tires

40.00 R57 46/90 R57 50/80 R57

Note

Extended life wheel stations optional.

Braking System

Service Brakes

Four-Corner, Wet Disc, Oil Cooled, Hydraulically Actuated

Four-Corner Wet Disc Oil Cooled Hydraulically Actuated

Front Wet Disc Brake Surface Area

61270 cm²

9487 in²

81693 cm²

12662 in²

89727 cm²

13907 in²

Rear - Wet Disc Brake Surface Area

89728 cm²

13908 in²

134590 cm²

20861 in²

134590 cm²

20861 in²

Standards

Service and Secondary: ISO 3450:2011

(Service and Secondary) ISO 3450:2011

Parking Brake

Four corner, multi disc, spring applied, hydraulically released

Four-corner, Multi-disc, Spring applied, Hydraulically Released

Four-corner Multi-disc Spring applied Hydraulically Released

Capacity - MSD II - 100% Fill Factor

Struck

72 m^3 / 94 yd^3

Heaped (SAE 2:1)

99 m^3 / 129 yd^3

Note

Consult your local Cat dealer for body recommendations.

Body Hoists

Type

Twin, two-stage hydraulic cylinders with snubbing valve.

Twin two-stage hydraulic cylinders with snubbing valve.

Pump Flow - High Idle

847 l/min

223 gal/min

403 l/min

106.5 gal/min

819 l/min

216 gal/min

Relief Valve Setting - Raise

17225 kPa

2500 psi

18950 kPa

2749 psi

20370 kPa

2955 psi

Body Raise Time - High Idle

15 s

14 s

22 s

Body Lower Time - Float

15.6 s

16 s

23 s

Body Power Down- High Idle

15.5 s

Body Power Down - High Idle

21 s

Suspension

Type

Self-contained nitrogen/oil cylinders, pin-to-pin mounting, top & bottom double shear clevis attachments

Self-contained nitrogen/oil cylinders, pin-to-pin mounting, top and bottom double shear clevis attachments

Self-contained nitrogen/oil cylinders pin-to-pin mounting top and bottom double shear clevis attachments

Effective Cylinder Stroke - Front

320 mm

12.6 in

104.65 mm

4.12 in

317 mm

12 in

Effective Cylinder Stroke - Rear

165 mm

6.5 in

93.22 mm

3.67 in

165 mm

7 in

Rear axle - Oscillation

+/- 5.4 degrees

+/- 5 degrees

4.9 degrees

Service Refill Capacities

Fuel Tank

1552 l

410 gal (US)

4546 l

1000 gal (US)

2839 l

750 gal (US)

Diesel Exhaust Fluid Tank

136 l

36 gal (US)

233 l

62 gal (US)

235 l

62 gal (US)

Cooling System

476 l

126 gal (US)

679 l

180 gal (US)

1074 l

284 gal (US)

Crankcase

204 l

54 gal (US)

291 l

77 gal (US)

312 l

82 gal (US)

Front Wheels - Each

27 l

7.1 gal (US)

22 l

5.8 gal (US)

30 l

8 gal (US)

Differential - Final Drives

527 l

139 gal (US)

984 l

260 gal (US)

Steering Tank

110 l

29 gal (US)

Steering System - Includes Tank

117 l

31 gal (US)

175 l

46 gal (US)

290 l

77 gal (US)

Brake/Hoist Tank

511 l

135 gal (US)

Brake Hoist System - Includes Tank

541 l

143 gal (US)

1315 l

347 gal (US)

1315 l

347 gal (US)

Torque Converter - Transmission System - Including Sump

175 l

46 gal (US)

209 l

55 gal (US)

Fuel Tank - Standard

2500 l

550 gal (US)

Fuel Tank (Tier 4)

2500 l

55 gal (US)

Differentials

610 l

161 gal (US)

Steering System

160 l

42 gal (US)

Brake Hoist System

640 l

169 gal (US)

Fuel Tank - Optional

4922 l

1300 gal (US)

Torque Converter/Transmission System - Including Sump

209 l

55 gal (US)

Torque Converter Sump

102 l

27 gal (US)

Cab

Air Conditioning

HFC - 134A refrigerant: 24,500 Btu/h

(HFC - 134A refrigerant) 24,500 Btu/hr

(HFC - 134A refrigerant) 9.3 kW 31733 BTU/hr

Heater / Defroster

33300 Btu/h

11 kW

36510 Btu/h

Note

The operator sound pressure level, 77 dB(A) with direct drive and 75 dB9A) with optional clutch, tested to ISO 6396:2008.

Ambient capabilities down to -30C (-22F) for heater/defroster and up to 50C (122F) for air conditioning.

ROPS Standards (1)

ROPS (Rollover Protective Structure) meets ISO 3471:2008 for Operator and ISO 13459:2012 for Trainer.

The operator sound pressure level, 77 dB(A) with direct drive and 75 dB(A) with optional clutch, tested to ISO 6396:2008.

FOPS Standards

FOPS (Falling Objects Protective Structure) meets ISO 3449:2005 Level II for Operator and ISO 13459:2012 Level II for Trainer.

FOPS (Falling Objects Protective Structure) meets ISO 3449:2005 Level II for Operator and ISO 13459:2012 Level II for Trainer

ROPS Standards (2)

ROPS (Rollover Protective Structure) meets ISO 3471:2008 for Operator and ISO 13459:2012 for Trainer.

ROPS (Rollover Protective Structure) meets ISO 3471:2008 for Operator and ISO 13459:2012 for Trainer

Steering

Steer Angle

25.1 °

36.07 °

36 °

Turning Diameter - ISO 7457:1997 (33.00R51 tires)

29.4 m

96.6 ft

Steering Standards

ISO 5010:2019

ISO 5010:2007

ISO 5010:2019

Turning Diameter - Front

28 m

93 ft

Dimensions (All dimensions are approximate. MSD II Body, 33R51 tires, unloaded machine.)

Height - Top of ROPS

5208 mm

17.09 ft

Overall Body Length

11985 mm

39.32 ft

Inside Body Length

8318 mm

27.29 ft

Overall Length

11957 mm

39.23 ft

Wheel Base

5180 mm

17 ft

Rear Axle - Tail

3829 mm

12.56 ft

Ground Clearance

1004 mm

3.29 ft

Dump Clearance

1128 mm

3.7 ft

Loading Height - Empty

5299 mm

17.39 ft

Inside Body Depth - Maximum

2790 mm

9.15 ft

Overall Height - Body Raised

12032 mm

39.48 ft

Operating Width

7535 mm

24.72 ft

Centerline Front Tire Width

4850 mm

15.91 ft

Engine Guard Clearance

1038 mm

3.41 ft

Overall Canopy Width

7562 mm

24.81 ft

Outside Body Width

6714 mm

22 ft

Inside Body Width

6010 mm

19.72 ft

Front Canopy Height

6035 mm

19.8 ft

Rear Axle - Clearance

990 mm

3.25 ft

Centerline of Rear Dual Tire Width

4285 mm

14.06 ft

Overall Tire Width

6277 mm

20.59 ft

Capacity - HP Body - 100% Fill Factor

Struck

77 m3(101 yd3)

112.6-151 m3 (147-197.5 yd3)

Heaped (SAE 2:1)*

143 m3(187 yd2)

162-190 m3 (212-249 yd3)

Note (1)

Consult your local Cat dealer for body recommendations

Dimensions (Approximate)

Height - Top of ROPS

18.25 ft

5550 mm

Overall Body Length

42.5 ft

12945 mm

Inside Body Length

28.67 ft

8730 mm

Overall Length

42.58 ft

12970 mm

Wheel Base

18.67 ft

57000 mm

Rear Axle - Tail

12.67 ft

3856 mm

Ground Clearance

4.25 ft

1304 mm

Dump Clearance

5.17 ft

1585 mm

Loading Height - Empty

20.17 ft

6147 mm

Rear Sidewall Height

3.33 ft

1010 mm

Inside Body Depth - Maximum

10.08 ft

3075 mm

Overall Height - Body Raised

37.83 ft

11534 mm

Operating Width

25.67 ft

7822 mm

Centerline Front Tire Width

17.75 ft

5410 mm

Engine Guard Clearance

4.25 ft

1290 mm

Overall Canopy Width

25.5 ft

7769 mm

Outside Body Width

23.33 ft

7123 mm

Inside Body Width

22.67 ft

6920 mm

Front Canopy Height

22.08 ft

6739 mm

Rear Axle - Clearance

4.17 ft

1263 mm

Centerline of Rear Dual Tire Width

15.42 ft

4695 mm

Overall Tire Width

23.33 ft

7120 mm

Sound

Sound Standards (1)

The operator sound pressure level 74 dB(A) complies with ISO 6394 and ISO 6396.

1300 881 064

Off-Highway Trucks

Compare Models

Off-Highway Trucks

Compare Models

Engine

Weights - Approximate

Weight Distributions - Approximate

Final Drives

Transmission

Tires

Braking System

Capacity - MSD II - 100% Fill Factor

Body Hoists

Suspension

Service Refill Capacities

Cab

Steering

Dimensions (All dimensions are approximate. MSD II Body, 33R51 tires, unloaded machine.)

Capacity - HP Body - 100% Fill Factor

Dimensions (Approximate)

Sound
