Excavators
Compare Models
UNITS:
Metric
Imperial
Engine
Net Power
33.6 kW
45 hp
33.6 kW
45 hp
41.7 kW
55.9 hp
Engine Model
C1.7 Turbo
C1.7 Turbo
C1.7 Turbo
C1.7 Turbo
Cat C2.4 Turbo
Cat C2.4 Turbo
Gross Power - 2,400 rpm - SAE J1995:2014
36.1 kW
48.4 hp
36.1 kW
48.4 hp
-
Bore
84 mm
3.3 in
84 mm
3.3 in
87 mm
3.4 in
Emissions
Meets U.S. EPA Tier 4 Final and EU Stage V emission standards.
Meets U.S. EPA Tier 4 Final and EU Stage V emission standards.
Meets U.S. EPA Tier 4 Final and EU Stage V emissions standards.
Meets U.S. EPA Tier 4 Final and EU Stage V emissions standards.
-
Stroke
100 mm
3.9 in
100 mm
3.9 in
102.4 mm
4 in
Displacement
1.662 l
101 in³
1.662 l
101 in³
2.43 l
148 in³
Net Power - 2,400 rpm - ISO 9249, 80/1269/EEC
33.6 kW
45 hp
33.6 kW
45 hp
-
Note
Net power advertised is the power available at the flywheel when the engine is at rated speed and rated power when the engine is installed with the factory configured fan, air intake system, exhaust system, and alternator with a minimum alternator load.
Net power advertised is the power available at the flywheel when the engine is at rated speed and rated power when the engine is installed with the factory configured fan, air intake system, exhaust system, and alternator with a minimum alternator load.
Advertised power is tested per the specified standard in effect at the time of manufacture.
Advertised power is tested per the specified standard in effect at the time of manufacture.
-
Gross Power - ISO 14396
-
-
43.2 kW
57.9 hp
Net Power @ 2,200 rpm - U.S. EPA Tier 4 Final/EU Stage V - ISO 9249/EEC 80/1269
-
-
41.7 kW
55.9 hp
Weights
Operating Weight
4475 kg
9867 lb
5754 kg
12688 lb
7150 kg
15766 lb
Minimum Operating Weight with Canopy*
3925 kg
8655 lb
5006 kg
11038 lb
6410 kg
14134 lb
Maximum Operating Weight with Canopy**
4375 kg
9647 lb
5665 kg
12491 lb
7090 kg
15633 lb
Note (2)
**Maximum Weight is based on steel tracks, operator, full fuel tank, long stick, straight blade, extra counterweight and no bucket.
**Maximum Weight is based on steel tracks, operator, full fuel tank, long stick, straight blade, extra counterweight and no bucket.
**Maximum Weight is based on steel tracks with pads, operator, full fuel tank, long stick, straight blade, extra counterweight and no bucket.
**Maximum Weight is based on steel tracks with pads, operator, full fuel tank, long stick, straight blade, extra counterweight and no bucket.
**Maximum Weight is based on steel tracks with pads, extra counterweight, operator, full fuel tank, long stick, fixed blade and no bucket.
**Maximum Weight is based on steel tracks with pads, extra counterweight, operator, full fuel tank, long stick, fixed blade and no bucket.
Note (1)
*Minimum Weight is based on rubber tracks, operator, full fuel tank, standard stick, straight blade, no bucket and no extra counterweight.
*Minimum Weight is based on rubber tracks, operator, full fuel tank, standard stick, straight blade, no bucket and no extra counterweight.
*Minimum Weight is based on rubber tracks, operator, full fuel tank, standard stick, straight blade, no bucket and no extra counterweight.
*Minimum Weight is based on rubber tracks, operator, full fuel tank, standard stick, straight blade, no bucket and no extra counterweight.
*Minimum Weight is based on rubber tracks, operator, full fuel tank, standard stick, fixed blade and no bucket.
*Minimum Weight is based on rubber tracks, operator, full fuel tank, standard stick, fixed blade and no bucket.
Maximum Operating Weight with Cab**
4475 kg
9867 lb
5764 kg
12710 lb
7150 kg
15766 lb
Minimum Operating Weight with Cab*
4025 kg
8875 lb
5105 kg
11257 lb
6470 kg
14266 lb
Weight Increase from Minimum Configuration
Steel Tracks
195 kg
430 lb
-
-
Counterweight
225 kg
496 lb
242 kg
534 lb
250 kg
551 lb
Angle Blade
110 kg
243 lb
92 kg
203 lb
102 kg
225 lb
Long Stick
30 kg
66 lb
34 kg
75 lb
44 kg
97 lb
Steel Tracks with Pads
-
375 kg
827 lb
375 kg
827 lb
XTC Carriage (no tool)
-
-
64 kg
141 lb
Travel System
Ground Pressure - Minimum Weight
28.7 kPa
4.2 psi
27.3 kPa
4 psi
35.4 kPa
5.1 psi
Maximum Traction Force - Low Speed
32.6 kN
7329 lbf
50.5 kN
11353 lbf
56 kN
12589 lbf
Travel Speed - Low
3.5 km/h
2.2 mile/h
2.8 km/h
1.7 mile/h
2.8 km/h
1.7 mile/h
Ground Pressure - Maximum Weight
33.8 kPa
4.9 psi
32.2 kPa
4.7 psi
39.1 kPa
5.7 psi
Travel Speed - High
5.2 km/h
3.2 mile/h
5 km/h
3.1 mile/h
5 km/h
3.1 mile/h
Maximum Traction Force - High Speed
19 kN
4271 lbf
24.7 kN
5553 lbf
31 kN
6969 lbf
Gradeability - Maximum
30 degrees
30 degrees
30 degrees
30 degrees
30 degrees
30 degrees
Service Refill Capacities
Cooling System
11 l
2.9 gal (US)
11 l
2.9 gal (US)
10 l
2.6 gal (US)
Engine Oil
6 l
1.6 gal (US)
6 l
1.6 gal (US)
8 l
2.1 gal (US)
Hydraulic System
65 l
17 gal (US)
75 l
20 gal (US)
104 l
27.5 gal (US)
Fuel Tank
63 l
17 gal (US)
68 l
18 gal (US)
130 l
34.3 gal (US)
Hydraulic Tank
52 l
14 gal (US)
60 l
16 gal (US)
53 l
14 gal (US)
Hydraulic System
Operating Pressure - Travel
245 bar
3553 psi
265 bar
3843 psi
24500 kPa
3553 psi
Auxiliary Circuit - Secondary - Pressure
245 bar
3553 psi
265 bar
3843 psi
24500 kPa
3553 psi
Digging Force - Stick - Long
19.2 kN
4316 lbf
25.2 kN
5665 lbf
26.5 kN
5957 lbf
Auxiliary Circuit - Secondary - Flow
28 l/min
7 gal/min
28 l/min
7 gal/min
33 l/min
9 gal/min
Pump Flow at 2,400 rpm
96 l/min
25 gal/min
133 l/min
35 gal/min
151 l/min
40 gal/min
Operating Pressure - Swing
180 bar
2611 psi
200 bar
2901 psi
22500 kPa
3263 psi
Auxiliary Circuit - Primary - Flow
65 l/min
21 gal/min
80 l/min
21 gal/min
90 l/min
24 gal/min
Auxiliary Circuit - Primary - Pressure
245 bar
3553 psi
265 bar
3843 psi
24500 kPa
3553 psi
Note
Flow and pressure are not combinable. Under load, as flow rises pressure goes down.
Flow and pressure are not combinable. Under load, as flow rises pressure goes down.
Flow and pressure are not combinable. Under load, as flow rises pressure goes down.
Flow and pressure are not combinable. Under load, as flow rises pressure goes down.
-
Type
Load Sensing Hydraulics with Variable Displacement Piston Pump
Load Sensing Hydraulics with Variable Displacement Piston Pump
Load Sensing Hydraulics with Variable Displacement Piston Pump
Load Sensing Hydraulics with Variable Displacement Piston Pump
Load Sensing Hydraulics with Variable Displacement Piston Pump
Load Sensing Hydraulics with Variable Displacement Piston Pump
Digging Force - Stick - Standard
21 kN
4721 lbf
28.3 kN
6362 lbf
29.5 kN
6632 lbf
Digging Force - Bucket
38.2 kN
8588 lbf
49.2 kN
11061 lbf
51.5 kN
11578 lbf
Operating Pressure - Equipment
245 bar
3553 psi
265 bar
3843 psi
24500 kPa
3553 psi
Swing System
Boom Swing - Right
50 Degrees
50 Degrees
50 Degrees
50 Degrees
65 degrees
65 degrees
Machine Swing Speed
9 r/min
9 r/min
9 r/min
9 r/min
11 r/min
11 r/min
Boom Swing - Left
78 Degrees
78 Degrees
72 Degrees
72 Degrees
60 degrees
60 degrees
Blade
Angle Blade Height
360 mm
14.2 in
400 mm
15.7 in
400 mm
15.7 in
Straight Blade Height
360 mm
14.2 in
390 mm
15.4 in
390 mm
15.4 in
Straight Blade Width
1700 mm
66.9 in
1980 mm
78 in
1980 mm
78 in
Angle Blade Width
1700 mm
66.9 in
1980 mm
78 in
1980 mm
78 in
Angle Blade - Right
25 Degrees
25 Degrees
25 degrees
25 degrees
-
Angle Blade - Left
25 Degrees
25 Degrees
25 degrees
25 degrees
-
Certification - Cab and Canopy
Roll Over Protective Structure (ROPS)
ISO 12117-2:2008
ISO 12117-2:2008
ISO 12117-2:2008
ISO 12117-2:2008
Top Guard
ISO 10262:1998 (Level I)
ISO 10262:1998 (Level I)
ISO 10262:1998 Level I
ISO 10262:1998 Level I
Tip Over Protective Structure (TOPS)
ISO 12117:1997
ISO 12117:1997
-
Sound
Average Exterior Sound Pressure (ISO 6395:2008)
97 dB(A)
97 dB(A)
97 dB(A)
97 dB(A)
99 dB(A)
99 dB(A)
Operator Sound Pressure (ISO 6396:2008)
76 dB(A)
76 dB(A)
76 dB(A)
76 dB(A)
72 dB(A)
72 dB(A)
Note
European Union Directive “2000/14/EC”
European Union Directive “2000/14/EC”
European Union Directive "2000/14/EC"
European Union Directive "2000/14/EC"
European Union Directive “2000/14/EC”
European Union Directive “2000/14/EC”
Dimensions - Standard Stick
Maximum Reach - Ground Level
5200 mm
204.7 in
5590 mm
220.1 in
6130 mm
241 in
Vertical Wall
2395 mm
94.3 in
2335 mm
91.9 in
2710 mm
107 in
Note
*Overall Shipping Length depends on blade position during shipment.
*Overall Shipping Length depends on blade position during shipment.
*Overall Shipping Length depends on blade position during shipment.
*Overall Shipping Length depends on blade position during shipment.
-
Tail Swing with Counterweight
1300 mm
51.2 in
1200 mm
47.2 in
1475 mm
58 in
Boom In Reach
2255 mm
88.8 in
2570 mm
101.2 in
2485 mm
98 in
Dig Depth
3210 mm
126.4 in
3420 mm
134.6 in
3710 mm
146 in
Maximum Dig Height
5040 mm
198.4 in
5215 mm
205.3 in
5835 mm
230 in
Maximum Blade Height
420 mm
16.5 in
400 mm
15.7 in
415 mm
16 in
Swing Bearing - Height
557 mm
21.9 in
619 mm
24.4 in
672 mm
27 in
Boom Swing - Left
530 mm
20.9 in
615 mm
24.2 °
735 mm
29 in
Stick Length
1395 mm
54.9 in
1351 mm
53.2 in
1580 mm
62 in
O/A Undercarriage Length
2210 mm
87 in
2580 mm
101.6 in
2580 mm
102 in
Track Belt/Shoe Width
350 mm
13.8 in
400 mm
15.7 in
400 mm
16 in
Boom Height - Shipping Position
1620 mm
63.8 in
1820 mm
71.7 in
-
Boom Swing - Right
730 mm
28.7 in
865 mm
34.1 °
910 mm
36 in
Maximum Dump Clearance
3645 mm
143.5 in
3700 mm
145.7 in
4325 mm
170 in
Ground Clearance
305 mm
12 in
335 mm
13.2 in
306 mm
12 in
Maximum Reach
5330 mm
209.8 in
5755 mm
226.6 in
6295 mm
248 in
O/A Shipping Height
2540 mm
100 in
2550 mm
100.4 in
-
Tail Swing without Counterweight
1205 mm
47.4 in
1095 mm
43.1 in
1350 mm
53 in
Maximum Blade Depth
475 mm
18.7 in
650 mm
25.6 in
600 mm
24 in
Overall Shipping Length*
4950 mm
194.9 in
5305 mm
208.9 in
-
Transport Height
-
-
1755 mm
69 in
Cab Height
-
-
2545 mm
100 in
Width over Upper House
-
-
1950 mm
77 in
O/A Track Width
-
-
1980 mm
78 in
O/A Shipping Length
-
-
5975 mm
235 in
Dimensions - Long Stick
Dig Depth
3510 mm
138.2 in
3670 mm
144.5 in
4110 mm
162 in
Maximum Blade Depth
475 mm
18.7 in
650 mm
25.6 in
600 mm
24 in
O/A Shipping Height
2540 mm
100 in
2550 mm
100.4 in
-
Maximum Dump Clearance
3740 mm
147.2 in
3845 mm
151.4 in
4610 mm
182 in
Stick Length
1695 mm
66.7 in
1601 mm
63 in
1980 mm
78 in
Maximum Dig Height
5125 mm
201.8 in
5355 mm
210.8 in
6130 mm
241 in
Maximum Reach - Ground Level
5445 mm
214.4 in
5835 mm
229.7 in
6535 mm
257 in
Track Width
1700 mm
66.9 in
1980 mm
78 in
-
Tail Swing with Counterweight
1300 mm
51.2 in
1200 mm
47.2 in
1475 mm
58 in
Swing Bearing - Height
557 mm
21.9 in
619 mm
24.4 in
672 mm
27 in
Boom Height - Shipping Position
1910 mm
75.2 in
1895 mm
74.6 in
-
Boom Swing - Left
530 mm
20.9 in
24.2 °
615 mm
735 mm
29 in
Maximum Reach
5570 mm
219.3 in
5990 mm
235.8 in
6685 mm
263 in
Boom In Reach
2340 mm
92.1 in
2580 mm
101.6 in
2960 mm
117 in
Boom Swing - Right
730 mm
28.7 in
865 mm
34.1 °
910 mm
36 in
Track Belt/Shoe Width
350 mm
13.8 in
400 mm
15.7 in
400 mm
16 in
Vertical Wall
2535 mm
99.8 in
2560 mm
100.8 in
3165 mm
125 in
Maximum Blade Height
420 mm
16.5 in
400 mm
15.7 in
415 mm
16 in
Note
*Overall Shipping Length depends on blade position during shipment.
*Overall Shipping Length depends on blade position during shipment.
*Overall Shipping Length depends on blade position during shipment.
*Overall Shipping Length depends on blade position during shipment.
-
Overall Shipping Length*
4950 mm
194.9 in
5340 mm
210.2 in
-
Ground Clearance
305 mm
12 in
335 mm
13.2 in
306 mm
12 in
O/A Undercarriage Length
2210 mm
87 in
2580 mm
101.6 in
2580 mm
102 in
Tail Swing without Counterweight
1205 mm
47.4 in
1095 mm
43.1 in
1350 mm
53 in
O/A Track Width
-
-
1980 mm
78 in
Transport Height
-
-
2410 mm
95 in
Width over Upper House
-
-
1950 mm
77 in
O/A Shipping Length
-
-
5950 mm
234 in
Cab Height
-
-
2545 mm
100 in
Sustainability
Recyclability
96%
96%
96%
96%
96%
96%
Certification - Cab
Top Guard
ISO 10262:1998 (Level II)
ISO 10262:1998 (Level II)
Roll Over Protective Structure (ROPS)
ISO 12117-2:2008
ISO 12117-2:2008
Tip Over Protective Structure (TOPS)
ISO 12117:1997
ISO 12117:1997
Air Conditioning System
Air Conditioning
The air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a (Global Warming Potential = 1287). The system contains 0.9 kg of refrigerant which has a CO2 equivalent of 1.287 metric tonnes.
The air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a (Global Warming Potential = 1287). The system contains 0.9 kg of refrigerant which has a CO2 equivalent of 1.287 metric tonnes.
