Buckets - Compact Wheel Loader

1.0 m3 (1.3 yd3), Skid Steer Coupler, Bolt-On Cutting Edge

High capacity increases productivity in handling light materials.

Specifications
Features

Overview

Cat® Light Material Buckets leverage many of the same features found in the General Purpose Bucket but with higher volume capacities to handle less dense materials such as top soil, fertilizer, wood chips and many more.

UNITS:

Metric

Imperial

Width	1890 mm	74.4 in
Weight	391 kg	862 lb
Height	1003 mm	39.5 in
Length	991 mm	39 in
Capacity	1 m³	1.3 yd³
Base Edge Thickness	20 mm	0.8 in
Cutting Edge Thickness	16 mm	0.6 in
Interface Type	Skid Steer Coupler	Skid Steer Coupler

Features

Application

Designed to handle low density materials such as mulch, wood chips, dry topsoil, fertilizer, livestock feed and snow.

High Capacity

High capacity increases productivity in handling light materials.

Superior Loading

Long bucket floor length, combined with large radius back wrapper, provides superior material loading and dumping, resulting in greater payloads and quicker cycle times.

Rugged Design

Hardened steel base and side cutting edges provide excellent penetration, durability and wear life.

Overview

UNITS:

Metric

Imperial

Width	1890 mm	74.4 in
Weight	391 kg	862 lb
Height	1003 mm	39.5 in
Length	991 mm	39 in
Capacity	1 m³	1.3 yd³
Base Edge Thickness	20 mm	0.8 in
Cutting Edge Thickness	16 mm	0.6 in
Interface Type	Skid Steer Coupler	Skid Steer Coupler

Features

Application

Designed to handle low density materials such as mulch, wood chips, dry topsoil, fertilizer, livestock feed and snow.

High Capacity

High capacity increases productivity in handling light materials.

Superior Loading

Long bucket floor length, combined with large radius back wrapper, provides superior material loading and dumping, resulting in greater payloads and quicker cycle times.
