Buckets - Excavator
1200 mm (47 in), 159 L (5.6 ft3), Pin On, 40 mm (1.6 in)
Used in ditch cleaning, sloping, grading and other finishing work.
Request a quote
Overview
Tilting Ditch Cleaning Buckets for Cat® Mini Excavators are ideal for cleaning wide trenches, loading materials, slope cutting, grading and finishing work in construction, landscaping and road maintenance applications.
UNITS:
Metric
Imperial
| Width | 1200 mm | 47.2 in |
| Capacity | 158.6 l | 5.6 ft³ |
| Weight | 162.3 kg | 357.8 lb |
| Base Edge Thickness | 16 mm | 0.6 in |
| Tip Radius | 728 mm | 28.7 in |
| Interface Type | Pin On | Pin On |
Features
Application
Ideal for cleaning wide trenches, loading materials, slope-cutting and profiling, grading and finishing work in construction, landscaping and road maintenance applications.Bucket Design
Formed back wrapper design enhances bucket loading ability and production.Superior Bucket Fill
Optimum wrapper angle and no sharp corners promote superior bucket fill and reduce material packing.Bucket Shape
Enhanced bucket shape allows material to flow more easily. Tapered bucket sidewalls allow for easy dumping of sticky material.Overview
Tilting Ditch Cleaning Buckets for Cat® Mini Excavators are ideal for cleaning wide trenches, loading materials, slope cutting, grading and finishing work in construction, landscaping and road maintenance applications.
UNITS:
Metric
Imperial
| Width | 1200 mm | 47.2 in |
| Capacity | 158.6 l | 5.6 ft³ |
| Weight | 162.3 kg | 357.8 lb |
| Base Edge Thickness | 16 mm | 0.6 in |
| Tip Radius | 728 mm | 28.7 in |
| Interface Type | Pin On | Pin On |
Features
Application
Ideal for cleaning wide trenches, loading materials, slope-cutting and profiling, grading and finishing work in construction, landscaping and road maintenance applications.Bucket Design
Formed back wrapper design enhances bucket loading ability and production.Superior Bucket Fill
Optimum wrapper angle and no sharp corners promote superior bucket fill and reduce material packing.Bucket Shape
Enhanced bucket shape allows material to flow more easily. Tapered bucket sidewalls allow for easy dumping of sticky material.Related Products
