Buckets - Loader

2.3 m3 (3.0 yd3), Pin On, Bolt-On Cutting Edge

Performance Series Flat Floor, General Purpose Buckets utilize a long flat floor that delivers improved results when back dragging and grading.

Request a quote

Specifications
Features

Overview

Cat® Flat Floor Buckets are Performance Series, General Purpose Buckets that incorporate a specially designed long floor and a rear cutting edge to provide optimum results and productivity when performing light grading or back-dragging—while retaining all the premium loading-characteristic of the Performance Series.

UNITS:

Metric

Imperial

Width	2532 mm	99.7 in
Height	1349 mm	53.1 in
Weight	1025 kg	2259.7 lb
Length	1471 mm	57.9 in
Capacity	2.3 m³	3 yd³
Base Edge Thickness	25 mm	1 in
Cutting Edge Thickness	25 mm	1 in
Interface Type	Pin On	Pin On

Features

Application

Ideal for back dragging and grading applications. The fill factor for Performance Series buckets can be up to 115% on top of the specified capacity.

Rugged Design

Additional wear plates on bottom surface of bucket improves bucket life in coarse aggregate applications.

Performance Series Technology

Performance Series Technology - Innovations in bucket design that improve load-ability of buckets, increasing productivity and decreasing fuel costs.

Maximum Machine Usage

Bucket capacity and loading characteristics are matched to machine capabilities to ensure maximum usage and productivity.
