Photo Videos

Buckets - Loader

1.9 m3 (2.5 yd3), 2550 mm (100 in), Pin On, Bolt-On Cutting Edge

General Purpose Performance Series buckets provides higher fill factors and material retention in load and carry applications, as well as grading, leveling and dumping in a wide variety of applications and materials.

Request a quote

Specifications
Features

Overview

Cat® General Purpose Performance Series Buckets provide good all-around performance for stockpiling, re-handling, excavating and bank loading. As the name suggests, these buckets work well in loading from stockpiles as well as bank loading. Performance Series Buckets utilize a system-based approach to balance bucket shape against the machine's linkage, weight, lift and tilt capacities. The result is a bucket optimized for performance and productivity, and intended for use in production applications. The benefits of this design bring higher fill factors and material retention.

UNITS:

Metric

Imperial

Width	2550 mm	100 in
Height	1240 mm	48.8 in
Weight	811 kg	1787.9 lb
Length	1168 mm	46 in
Capacity	1.9 m³	2.5 yd³
Base Edge Thickness	25 mm	1 in
Interface Type	Pin On	Pin On

Features

Application

General Purpose Performance Series Buckets provide good all-around performance for stockpiling, re-handling, excavating, and bank loading. As the name suggests, these buckets work well in loading from stockpiles as well as bank loading. They are designed for standard breakout forces and abrasion conditions. Ideal for back dragging and grading applications. The fill factor for Performance Series buckets can be up to 115% on top of the specified capacity.

Integrated Spill Guard

Integrated Spill Guard provides protection of machine linkage and improved load retention by preventing material spillage.

Rounded Sidebars

Rounded sidebars help funnel material into the bucket and retain it.

Performance Series Profile

Performance Series profile for easy loading and maximum carry load.

Open Throat Design

Open throat design improves heap size and fill factor.

Overview

UNITS:

Metric

Imperial

Width	2550 mm	100 in
Height	1240 mm	48.8 in
Weight	811 kg	1787.9 lb
Length	1168 mm	46 in
Capacity	1.9 m³	2.5 yd³
Base Edge Thickness	25 mm	1 in
Interface Type	Pin On	Pin On
