Buckets - Mining Shovels
10.4 m³ (13.6 yd³) - 472-6127
Cat Coal buckets are high-capacity buckets designed for low density, high cohesion material, such as coal or sand. Light weight construction and straight lip design with small sized GET allow for maximum payload and material movement. Coal buckets have the Light Duty wear package. This package utilizes hardened plates on the exterior of the bucket in the highest wear areas and has optional coal breakers.
Request a quote
Overview
Cat Coal buckets are high capacity buckets for maximum material movement. Light weight construction for increased bucket volume and straight lip design with small sized GET allow for maximum payload. Special high strength steel with wear resistance is used for the plate lip. Coal buckets have the General Duty wear package. This package utilizes hardened plates on the exterior of the bucket in the highest wear areas and has optional coal breakers.
UNITS:
Metric
Imperial
| Material Density | 1 t/m³ | 1686 lb/yd³ |
| Wear Package | Light Duty - Coal | Light Duty - Coal |
| Ground Engaging Tool (GET) System | K150 | K150 |
| Machine Model | 6015 | 6015 |
| Capacity | 10.4 m³ | 13.6 yd³ |
| Weight | 7504 kg | 16543 lb |
| Outer Width | 3040 mm | 119.6 in |
| Inner Width | 2841 mm | 111.8 in |
Overview
Cat Coal buckets are high capacity buckets for maximum material movement. Light weight construction for increased bucket volume and straight lip design with small sized GET allow for maximum payload. Special high strength steel with wear resistance is used for the plate lip. Coal buckets have the General Duty wear package. This package utilizes hardened plates on the exterior of the bucket in the highest wear areas and has optional coal breakers.
UNITS:
Metric
Imperial
| Material Density | 1 t/m³ | 1686 lb/yd³ |
| Wear Package | Light Duty - Coal | Light Duty - Coal |
| Ground Engaging Tool (GET) System | K150 | K150 |
| Machine Model | 6015 | 6015 |
| Capacity | 10.4 m³ | 13.6 yd³ |
| Weight | 7504 kg | 16543 lb |
| Outer Width | 3040 mm | 119.6 in |
| Inner Width | 2841 mm | 111.8 in |
