Forks
1676 mm (66 in)
Cat® Utility Forks are designed to handle a wide array of materials in a variety of operating conditions.
Request a quote
Overview
Cat® Utility Forks for Cat Skid Steer Loaders and Compact Track Loaders are designed for handling a variety of light materials in farming, ranching and landscaping applications. Primary uses include removal of dry compacted livestock waste, transport of small bales, handling of loose material such as straw and hay, loosening of bedding material and aeration of soil. NOTE: Utility forks are not designed for piercing and carrying large, round bales.
UNITS:
Metric
Imperial
| Width | 1676 mm | 66 in |
| Height | 581 mm | 22.9 in |
| Weight | 198 kg | 436.5 lb |
| Length | 924 mm | 36.4 in |
| Usable Tine Length | 637 mm | 25.1 in |
| Tine Diameter | 31.75 mm | 1.3 in |
| Number of Tines | 7 | 7 |
| Tine Width | 31.75 mm | 1.3 in |
| Interface Type | Skid Steer Coupler | Skid Steer Coupler |
Features
Application
Designed for handling a variety of light materials in farming, ranching and landscaping applications.
Primary Uses
Primary uses include removal of dry compacted livestock waste, transport of small bales, handling of loose materials such as straw and hay, loosening of bedding material and aeration of soil.
Movable / Replaceable Tines
The lower box channel is pre-drilled to accept various combinations of pin-on fork tines.
Serrated Step / Rubber Bumper
Serrated weld-on step provides safe ingress and egress from machine cab. Also, a bolt-on rubber bumper limits rack back travel on the larger Cat radial lift machines.
Not Designed for Large, Round Bales
NOTE: Utility Forks are not designed for piercing and carrying large, round bales.
