Rippers / Scarifiers

861 mm (34 in), 7-9 Ton Mini Excavators

For land clearing or site preparation in rock, quarry work and similar high-impact digging applications. Combine with a coupler for Rip & Load productivity.

Request a quote

Overview

Cat® Excavator Rippers offer a cost-effective alternative to blasting. In quarry production work, they offer a lower cost per ton, better product quality and less environmental impact than explosive excavation. They are the ideal tool for land clearing or site preparation in rock, quarry work and similar high-impact digging applications. Take productivity to the next level with a Cat Rip & Load package. A quick coupler switches you rapidly between the ripper, and an Extreme Duty Rock bucket. Pull the rock from the ground and load it with the same machine.

UNITS:

Metric

Imperial

Shank Length	861 mm	33.9 in
Weight	107 kg	235.9 lb
Overall Length	1066.09 mm	42 in
Width	344 mm	13.5 in
Tip Radius	1039 mm	40.9 in

Features

Application

Designed for land clearing or site preparation in rock, quarry work and similar high-impact digging applications.

Pin-On or Coupler

Available as pin-on, also works with several popular quick couplers.

Heavy Construction

Reinforced, one piece shank is made of Hardox® 400. Includes adjuster group and Cat® Ground Engaging Tools. Gussets on top plate designed to withstand side loads.

Serviceability

Teeth are common with Cat® buckets and thumbs.

Thumb Compatible

Curved shape works with existing thumbs.

Downloads

Cat® Rippers Product Brochure Download
