Thumbs
475 mm (19 in) 6 Teeth/2 Tines
Utility Thumbs offer hydraulic functionality, with maximum interchangeability.
Request a quote
Overview
Cat® Utility Thumbs offer a cost-effective thumb design with hydraulic thumb control, combined with wide compatibility with machines, buckets and couplers.
UNITS:
Metric
Imperial
| Length | 1219 mm | 48 in |
| Stored Height | 464 mm | 18.3 in |
| Overall Width | 475 mm | 18.7 in |
| Weight | 157.5 kg | 347.2 lb |
| Rotation | 133 Degrees | 133 Degrees |
| Number of Teeth/Tines | 6/2 | 6/2 |
| Tine Spacing | 254 mm | 10 in |
| Tine Thickness | 20 mm | 0.8 in |
| Tines Included | Yes | Yes |
| Machine Class | 7-9 Ton Mini Hydraulic Excavators | 7-9 Ton Mini Hydraulic Excavators |
| Interface Type | Pin On (Pin Grabber) | Pin On (Pin Grabber) |
Features
Application
Cat® Utility thumbs are utilitarian in design. This style is perfect for the excavator that could benefit from a thumb for handling smaller size and lighter weight material on an occasional basis. They are best suited for the machine that does not handle material all day long.Versatile
Utility thumbs are universal in that they work well with most all buckets and couplers. They are well-suited for fleets with a mix of machines with varying bucket and coupler combinations.Easy Installation
An optional bracket can be welded onto the stick allowing for an easy installation if machine was not already fitted with one from the factory.Cylinder Snubber
A snubber in the thumb cylinder cushions the thumb as it retracts to it's stored position, thus reducing wear on components from unnecessary jolts and frees operator to focus on other tasks.Shut-Off Valves/Quick Couplings
Allows for attachment of other work tools without removing thumb (ex. Hammer). The shut-off valve also functions as a hydraulic lock when not in use. Quick couplings allow the thumb to be disconnected and another tool used while the thumb is still attached to the stick.Retractable Thumb
Retractable thumb allows normal bucket loading when not in use.Cross-Tube Design
Maintains rigidity while offering optimized visibility for better site into bucket when lifting irregular loads.Thumb Tine Spacing
Optimized tine and bucket tooth spacing allows thumb and bucket to mesh together without interference. Different width buckets can be used with the same thumb for maximum flexibility.Overview
Cat® Utility Thumbs offer a cost-effective thumb design with hydraulic thumb control, combined with wide compatibility with machines, buckets and couplers.
UNITS:
Metric
Imperial
| Length | 1219 mm | 48 in |
| Stored Height | 464 mm | 18.3 in |
| Overall Width | 475 mm | 18.7 in |
| Weight | 157.5 kg | 347.2 lb |
| Rotation | 133 Degrees | 133 Degrees |
| Number of Teeth/Tines | 6/2 | 6/2 |
| Tine Spacing | 254 mm | 10 in |
| Tine Thickness | 20 mm | 0.8 in |
| Tines Included | Yes | Yes |
| Machine Class | 7-9 Ton Mini Hydraulic Excavators | 7-9 Ton Mini Hydraulic Excavators |
| Interface Type | Pin On (Pin Grabber) | Pin On (Pin Grabber) |
Features
Application
Cat® Utility thumbs are utilitarian in design. This style is perfect for the excavator that could benefit from a thumb for handling smaller size and lighter weight material on an occasional basis. They are best suited for the machine that does not handle material all day long.Versatile
Utility thumbs are universal in that they work well with most all buckets and couplers. They are well-suited for fleets with a mix of machines with varying bucket and coupler combinations.Easy Installation
An optional bracket can be welded onto the stick allowing for an easy installation if machine was not already fitted with one from the factory.Cylinder Snubber
A snubber in the thumb cylinder cushions the thumb as it retracts to it's stored position, thus reducing wear on components from unnecessary jolts and frees operator to focus on other tasks.Shut-Off Valves/Quick Couplings
Allows for attachment of other work tools without removing thumb (ex. Hammer). The shut-off valve also functions as a hydraulic lock when not in use. Quick couplings allow the thumb to be disconnected and another tool used while the thumb is still attached to the stick.Retractable Thumb
Retractable thumb allows normal bucket loading when not in use.Cross-Tube Design
Maintains rigidity while offering optimized visibility for better site into bucket when lifting irregular loads.Thumb Tine Spacing
Optimized tine and bucket tooth spacing allows thumb and bucket to mesh together without interference. Different width buckets can be used with the same thumb for maximum flexibility.Related Products
