Skid Steer and Compact Track Loaders

265

NEW

The Cat® 265 Compact Track Loader, with its vertical lift design, delivers extended reach and lift height for quick and easy truck loading. Its standard torsion suspension undercarriage system provides superior traction, flotation, stability, and speed to work in a wide range of applications and underfoot conditions.

Request a quote

Overview

Engine

UNITS:

Metric

Imperial

Gross Power - SAE J1995	55.3 kW	74.2 hp
Bore	110 mm	4.3 in
Displacement	2.8 l	171 in²
Net Power - ISO 9249	54.5 kW	73.1 hp
Net Power - SAE 1349	54.8 kW	73.5 hp
Peak Torque at 1,360 rpm SAE J1995	380 N·m	280 lb/ft
Engine Model	Cat® C2.8TA (turbo after-cooled)	Cat® C2.8TA (turbo after-cooled)
Stroke	90 mm	3.5 in

Hydraulic System

Hydraulic Flow - High Flow - Hydraulic Power (Calculated)	45.4 kW	60.9 hp
Hydraulic Flow - High Flow - Loader Hydraulic Flow	113 l/min	30 gal/min
Hydraulic Flow - High Flow - Loader Hydraulic Pressure	24130 kPa	3500 psi
Hydraulic Flow - High Flow XPS - Hydraulic Power (Calculated)	60.2 kW	80.7 hp
Hydraulic Flow - High Flow XPS - Maximum Loader Hydraulic Flow	129 l/min	34 gal/min
Hydraulic Flow - High Flow XPS - Maximum Loader Hydraulic Pressure	28000 kPa	4061 psi
Hydraulic Flow - Standard - Hydraulic Power (Calculated)	34.6 kW	46.4 hp
Hydraulic Flow - Standard - Loader Hydraulic Flow	86 l/min	23 gal/min
Hydraulic Flow - Standard - Loader Hydraulic Pressure	24130 kPa	3500 psi

Weights*

Operating Weight	4759 kg	10492 lb
Counterweight Adds to Operating Weight	125 kg	276 lb
Counterweight Adds to Operating Weight - ROC (35%)	78 kg	173 lb
Counterweight Adds to Operating Weight - Tip Load	224 kg	494 lb
Enclosed Cab Adds to Operating Weight	82 kg	180 lb
Enclosed Cab Adds to Operating Weight - ROC (35%)	34 kg	75 lb
Enclosed Cab Adds to Operating Weight - Tip Load	97 kg	214 lb
Note	*Operating Weight, Operating Specifications, and Dimensions are based on 2036 mm (80") low profile bucket with bolt on cutting edge, 450 mm (17.7") wide track, 75 kg (165 lb) operator, open canopy, mechanical suspension seat, HD battery with disconnect, standard flow hydraulics, manual coupler, and full fluids. No external counterweights, and no dual self-level/return-to-dig/work tool positioner	*Operating Weight, Operating Specifications, and Dimensions are based on 2036 mm (80") low profile bucket with bolt on cutting edge, 450 mm (17.7") wide track, 75 kg (165 lb) operator, open canopy, mechanical suspension seat, HD battery with disconnect, standard flow hydraulics, manual coupler, and full fluids. No external counterweights, and no dual self-level/return-to-dig/work tool positioner
Operating Weight - ROC (35%)	1280 kg	2823 lb
Operating Weight - ROC (50%)	1829 kg	4033 lb
Operating Weight - Tip Load	3659 kg	8066 lb

Service Refill Capacities

Cooling System	10.7 l	2.8 gal (US)
Engine Crankcase	8.2 l	2.2 gal (US)
Fuel Tank	120 l	31.7 gal (US)
Hydraulic System	36.8 l	9.7 gal (US)
Hydraulic Tank	26 l	6.9 gal (US)

Operating Specifications

Rated Operating Capacities - 35% Tipping Load	1280 kg	2823 lb
Breakout Force - Lift Cylinder	3057 kg	6739 lb
Breakout Force - Tilt Cylinder	3937 kg	8680 lb
Ground Contact Area - With 450 mm/17.7 in Track	1.46 m²	2268 in²
Ground Pressure - With 450 mm/17.7 in Track	31.9 kPa	4.6 psi
Rated Operating Capacities - 50% Tipping Load	1829 kg	4033 lb
Rated Operating Capacity with Optional Counterweight	1359 kg	2996 lb
Tipping Load	3659 kg	8066 lb

Dimensions

Bucket Pin Height - Carry Position	213 mm	8.4 in
Bucket Pin Height - Maximum Lift	3354 mm	132 in
Bucket Pin Reach - Maximum Lift	249 mm	9.8 in
Clearance at Maximum Lift and Dump	2655 mm	104.5 in
Departure Angle	28.2°	28.2°
Ground Clearance	216 mm	8.5 in
Height - Top of Cab	2115 mm	83.3 in
Length - Track on Ground	1626 mm	64 in
Length - With Bucket on Ground	3580 mm	140.9 in
Length - Without Bucket	2950 mm	116.1 in
Maximum Overall Height	4173 mm	164.3 in
Maximum Reach - With Arms Parallel to Ground	1187 mm	46.7 in
Overall Length - Track	2126 mm	83.7 in
Rack Back Angle - Maximum Height	85.3°	85.3°
Reach at Maximum Lift/Dump	638 mm	25.1 in
Roll Back Angle	27°	27°
Turning Radius from Center - Bucket (racked)	2229 mm	87.8 in
Turning Radius from Center - Coupler	1436 mm	56.5 in
Turning Radius from Center - Machine Rear	1741 mm	68.5 in
Vehicle Width (450 mm/17.7 in tracks)	1925 mm	75.8 in
Maximum Dump Angle	46.4°	46.4°

Cab

FOPS	ISO 3449:2005 Level I	ISO 3449:2005 Level I
ROPS	ISO 3471:2008	ISO 3471:2008

Power Train

Travel Speed - Forward or Reverse - One Speed	8 km/h	5 mile/h
Travel Speed - Forward or Reverse - Two Speed	13 km/h	8.1 mile/h

Features

Redesigned Operator Station

Redesigned Operator Station delivers a larger operating environment, and combined with additional seat travel, the 265 provides more space for operators of any size. The optional one-piece, sealed, and pressurized cab offers a clean and quiet workspace with excellent air distribution through optimally placed vents throughout the cab.

Ventilated and heated high-back air ride seat

Available ventilated and heated high-back air ride seat with seat mounted adjustable joystick controls deliver industry-leading operator comfort.

High-performance power train

High-performance power train provides selectable settings for drive power priority and maximum travel speed (overdrive) to customize the machine performance to match the task.

Three levels of auxiliary hydraulic performance

Three levels of auxiliary hydraulic performance available Standard Flow, High Flow, and High Flow XPS. Standard flow for attachments that require a base level of auxiliary flow and horsepower, High Flow boosts the auxiliary flow for applications that demand additional hydraulic flow for increased attachment performance, and the High Flow XPS hydraulic system provides maximum auxiliary hydraulic performance by delivering additional flow and additional pressure for the most demanding attachments and applications

Electronically controlled Cat C2.8TA (turbo after-cooled) engine

Electronically controlled Cat C2.8TA engine

Electronically controlled Cat C2.8TA (turbo after-cooled) engine delivers maximum horsepower across a wide RPM range and providing high torque for increased working performance, no matter the application.

Torsion suspension undercarriage and two-speed travel

Standard torsion suspension undercarriage and standard two-speed travel, combined with the optional Speed Sensitive Ride Control system improves operation on rough terrain, enabling better load retention, increased productivity, and greater operator comfort.

Advanced Touchscreen Monitor

The 20.3 cm (8-inch) Advanced Touchscreen Monitor offers cutting-edge functionality and control that includes an integrated radio, Bluetooth® connectivity, and multi-camera (side-view) option, and supports 32 different language choices.

Advanced Joysticks

Maximize machine capability and control with the Advanced Joysticks. The Advanced Joysticks provide unmatched control of machine functions and adjustments within the display without the operator having to remove his hands from the controls. This includes the on-joystick navigation of the Advanced Touchscreen Monitor, radio volume up/down/mute, creep activation, creep on/off, creep speed increment/decrement, one-button Smart Attachment control activation, and additional auxiliary control buttons that deliver single-button control of complex attachment functions

Ground-level access

Ground-level access to all daily service and routine maintenance points help reduce machine downtime for greater productivity.

Broad range of performance-matched Cat Attachments

Broad range of performance-matched Cat Attachments make the Cat Compact Track Loaders the most versatile machine on the job site.

Standard Equipment

STANDARD EQUIPMENT

Quick Coupler: Manual or Hydraulic
High Visibility Seat Belt: 50 mm (2 in), 75 mm (3 in), or 3-point lap/shoulder
Steel Imbed Rubber Track – 450 mm (17.7 in) bar tread, 450 mm (17.7 in) block tread
Dual Flange Front Idler/Single Flange Rear Idler or Triple Flange Front/Rear Idlers

PERFORMANCE PACKAGES

Performance Package HP1: Standard Flow Hydraulics
Performance Package HP3: High Flow XPS Hydraulics

COMFORT PACKAGES

Open canopy: Cup Holder, Cell Phone Pocket, choice of vinyl Seat (Mechanical Suspension, High Back/Heated/Air Ride Seat)
Enclosed Cab with heat and air conditioning: Side Windows, Cup Holder, Cell Phone Pocket, choice of Seat (Mechanical Suspension, High Back/Heated Air Ride Seat, High Back/Ventilated and Heated Air Ride Seat) and Door choice (Glass or Polycarbonate)

TECHNOLOGY PACKAGES

T2 – Standard Display, Standard Joysticks, traditional Key Start switch, and Rear-view camera.
T4 – Advanced Touchscreen Monitor, Advanced Joysticks, Push start, X-mount cell phone holder, and a Rear-view camera.
T5 – T4 + 2 additional side view cameras.

RADIO

Radio, none – for open canopy machines and countries not certified for Bluetooth® technology
Integrated AM/FM radio with Bluetooth technology. Includes USB port, 3.5 mm (0.13 in) AUX input, and BT microphone. Only for use with enclosed cab. Availability varies by country.
Integrated DAB+/AM/FM radio with Bluetooth technology. Includes USB port, 3.5 mm (0.13 in) AUX input, and BT microphone. Only for use with enclosed cab. Availability varies by country.

PRODUCT LINK™

Product Link™ Basic series PL243
Product Link Elite series PLE643

COOLING FAN

On-demand, variable speed hydraulic cooling fan
On-demand, variable speed hydraulic cooling fan, with automatic and manual purge reversing operation

GUARDING AND SEALING PACKAGES

HD0 – base guarding and sealing (engine air inlet rain cap, front cab to-frame sealing, and hydraulic fill access door)
HD1– intermediate guarding and sealing† (HD0 + cab-to-frame side sealing, lockable fuel fill access door, tilt cylinder guarding, and drive line bottom guarding.) †Some equipment varies by region.
HD2 – most comprehensive guarding and sealing† (HD1 + turbo guard, exhaust stack wrap, DPF wrap, quick disconnect guarding, fully enclosed drive line guarding, under step hydraulic lines guard cover, engine air inlet pre-cleaner.)

ELECTRICAL

Work Tool Electrical Harness
Heavy duty battery
Battery disconnect with lockout feature
12-volt Electrical System
85 Ampere Alternator
LED Work Lights
Auto Reverse Lights
Switch Backlighting
Interior LED Dome Light
Backup Alarm
Electrical Outlet, Beacon
Exterior Courtesy Lighting
Automatic Work light notification flash when parking brake is released

OPERATOR ENVIRONMENT

Full color LCD monitor: Creep speed control, Drive response adjustment, Implement response adjustment, Drive Power Priority adjustment, Language selection (× 32), Multi-operator Anti-theft Security System and Monitoring, Maintenance schedule and reminders, Event and Diagnostic Code monitoring, Date /Time/Units/Brightness settings, and Smart Technology for use with Smart Attachments.
Operator Warning System Indicators: Air Filter Restriction, Alternator Output, Armrest Raised/Operator Out of Seat, Engine Coolant Temperature, Engine Oil Pressure, Glow Plug Activation, Hydraulic Supply Filter Restriction, Hydraulic Oil Temperature, Park Brake Engaged, Engine Emission System (where applicable)
Gauges: Fuel Level, Hour Meter, Hydraulic Temperature, Hour Meter, Battery Voltage, Tachometer
Fold In Ergonomic Contoured Armrest
Control Interlock System, when operator leaves seat or armrest raised: Hydraulic System Disables, Hydrostatic Transmission Disables, Parking
Brake Engages
ROPS Cab, Tilt Up
FOPS, Level I
Top and Rear Windows
Floor Mat
Headliner
Interior Rearview Mirror
Horn
Hand (Dial) Throttle, Electronic
Seat Mounted Joystick Controls
Cell Phone Storage Pocket
Cup Holder
12-volt power port
Foot Throttle

HYDRAULICS

Selectable control pattern – ISO or H
Electro/hydraulic implement control
Electro/hydraulic hydrostatic transmission control
Speed sensor guarding
Heavy duty flat faced quick disconnects with integrated pressure release lever
Hydraulic oil level sight gauge

POWER TRAIN

Cat C2.8TA turbocharged, after-cooled diesel engine, meeting Brazil MAR-1 emission standards, equivalent to EU Stage IIIA: • Glow plugs starting aid • Liquid cooled, direct injection
Extended life antifreeze (–37° C, –34° F)
Air cleaner, dual element, radial seal
Scheduled Oil Sampling (S·O·SSM) Valve, Hydraulic Oil
Ecology drain – coolant
Radiator coolant level sight gauge
Radiator expansion bottle
Filter, hydraulic supply, cartridge type
Filter, hydraulic return, cartridge type
Filter, canister type, engine oil
Filter, canister type, fuel and water separator
Radiator/hydraulic oil
Cooler (side-by-side)
Spring applied, hydraulically released, parking brakes
Hydrostatic transmission
Lockable fuel cap
Hydraulic demand cooling fan
Auto engine idle

UNDERCARRIAGE

Torsion Suspension (4 independent torsion axles)
Two speed travel
Integrated tie downs on track frame (4)

FRAME

Machine tie down points (9)
Removable panels for machine frame cleanout
Support, lift arm
Steel rear and front bumpers, welded
Fuel fill, machine right hand side

OTHER

Auxiliary Hydraulics, Continuous Flow
Telematics, Product Link, Cellular
Steel engine door with replaceable louvers
Engine door – lockable
Work tool attachment coupler
Cat ToughGuardTM hose

Optional Equipment

OPTIONAL EQUIPMENT

External Counterweights
Beacon, LED
Engine Block Heater – 120V
Oil, Hydraulic, Cold Operation
4-point machine lifting eyes
Paint, Custom
Speed Sensitive Ride Control
Bluetooth Key Security
Attachment Hose Guide
Corrosion Inhibitor Coating
